Schüco AD UP 75 Doors

Schüco AD UP 75 Doors

Schüco AD UP 75 – highly insulated and reliable aluminum doors offering extensive design and integration possibilities for both residential and commercial buildings.

High Thermal Insulation

The high-efficiency profile ensures excellent energy performance.

Universal Application

Suitable for residential homes, offices, commercial spaces, and public buildings.

Comprehensive Design Freedom

A broad selection of premium hardware and architectural configurations to suit any vision.

Smart Integration

Fully compatible with access control, smart automation, and advanced management solutions.

Reliability and Performance

Engineered for high-traffic environments, ensuring long-term operational durability.

Insulation and Comfort

Advanced weather resistance guarantees a consistently comfortable living environment.

Technical Specifications

Thermal Transmittance Uf from ~1,4 W/(m²·K)
Max. door height up to ~3000 mm
Max. door width up to ~1400 mm
Max. glass / panel thickness up to ~53 mm
Max. leaf weight up to ~200 kg
Airtightness class 4
Watertightness up to E750
Wind load resistance class C3 / B3
Burglar resistance Up to RC2 (expandable to RC3 depending on the configuration)
Sound insulation Up to ~42 dB (depending on configuration)
Installation depth 75 mm
Min. visible face width ~147 mm
Technical Specifications

bfb Produkt des Jahres 2024
