Schüco ADS 75.SI Doors

Schüco ADS 75.SI Doors

Schüco ADS 75.SI (Super Insulated) is a high-performance aluminum system delivering peak thermal efficiency, security, and aesthetics. Designed for residential and commercial use, it integrates seamlessly with Schüco facades, windows, and automation.

Multi-Purpose Functionality

Engineered for both main entry doors and intensive-use building sections.

Advanced Connectivity

Easily integrated with building automation and security infrastructure to enhance comfort and operational control.

Superior Quality and Comfort

High-grade aluminum profiles ensure reliability, long-term durability, and a refined aesthetic, paired with advanced thermal insulation.

Superior Thermal Insulation

"Super Insulated" profiles ensure maximum heat retention and reduced energy consumption.

Burglary Resistance

Capable of achieving up to RC3 security classification.

Wind and Water Resistance

High-strength profiles guarantee maximum stability and weather tightness in severe weather conditions.

Technical Specifications

Thermal Transmittance Uf down to 1,6 W/m²K
Max. door height ~2500 mm
Max. door width ~1250 mm
Max. glass / panel thickness up to 72 mm
Max. leaf weight 200 kg
Airtightness class 2
Watertightness class 5A
Wind load resistance class C3
Burglar resistance up to RC3
Sound insulation Rw,P = 37 dB
Installation depth 75 mm
Min. visible face width 35 mm
