Schüco FWS 50 Facade System

Schüco FWS 50 Facade System

Schüco FWS 50 is a flexible aluminum facade system optimized for efficient installation. It integrates Schüco windows, doors, and sliding systems, and offers a certified sustainable Super Insulated (SI) version.

Modern and Aesthetic Design

A 50 mm visible profile width delivers an ultra-slim, minimalist facade appearance.

Design flexibility

The system combines seamlessly with Schüco AWS windows, ADS doors, and sliding systems, adapting to a wide range of applications.

Energy Efficiency and Sustainability

The FWS 50 is available in an SI (Super Insulated) version, which holds a Silver Cradle to Cradle Certified™ sustainability certification.

Easy Installation and Integration

Optimized components ensure reliable integration of mechatronic systems, including automated opening devices and solar shading.

Technical Specifications

Visible profile width 50 mm
Construction depth 6–255 mm (frame construction depth)
Max. glass / panel thickness ~62 mm
Max. openable sash weight ~1080 kg
Max. fixed element weight ~1080 kg
Thermal insulation Uf ≥ ~1,5 W/(m²·K) (standard version)
Airtightness AE
Watertightness RE 1200
Sound insulation ~48 dB(A)
Impact resistance I5/E5
Technical Specifications
